Manage Device Security
228
NETGEAR 24-Port Gigabit Smart Managed Pro Switch with PoE+ and 2 SFP Ports Model GS724TPv2
The default password is password.
The System Information page displays.
5. Select Security > ACL > Basic > MAC Rules.
The following figure does not show all columns.
6. From the ACL Name menu, select the MAC ACL.
7. In the Sequence Number field, enter a whole number in the range of 1 to 10 to identify the
rule.
8. From the Action menu, select the action that must be taken if a packet matches the rule’s
criteria:
• Permit. Forwards packets that meet the ACL criteria.
• Deny. Drops packets that meet the ACL criteria.
9. In the Assign Queue field, specify the hardware egress queue identifier that must be used
to handle all packets matching this ACL rule.
The valid range of queue IDs is 0 to 7.
10. From the Redirect Interface menu, select the egress interface to which the matching traffic
stream must be redirected, bypassing any forwarding decision normally performed by the
switch.
This field cannot be set if a mirror interface is already configured for the ACL rule.
11. From the Match Every menu, select whether each Layer 2 MAC packet must be matched
against the rule:
• True. Each packet must match the selected ACL rule.
• False. Not all packets need to match the selected ACL rule.
12. In the CoS field, specify the 802.1p user priority that must be compared against the
information in an Ethernet frame.
The valid range of values is 0 to 7.
13. In the Destination MAC field, specify the destination MAC address that must be compared
against the information in an Ethernet frame.
The valid format is xx:xx:xx:xx:xx:xx. The BPDU keyword can be specified using a
destination MAC address of 01:80:C2:xx:xx:xx.
