Transceiver modules and cables for SFP+ fiber ports
To enable fiber connections on the switch, SFP+ fiber ports accommodate standard
small form-factor pluggable (SFP) gigabit interface converters (GBICs, also referred to
as transceiver modules) and direct attach cables (DACs) for fiber connectivity. GBICs
and DACs are sold separately from the switch.
The switch supports the following NETGEAR SFP and SFP+ transceiver modules and
cables:
•
Short-reach fiber transceiver modules:
- AGM731F: SFP transceiver 1000BASE-SX, SFP multimode LC GBIC
•
Long-reach fiber transceiver modules:
- AGM732F: SFP transceiver 1000BASE-LX, SFP single mode LC GBIC
- AXM761: SFP+ transceiver 10GBASE-SR, SFP+ multimode LC GBIC
- AXM762: SFP+ transceiver 10GBASE-LR, SFP+ single mode LC GBIC
- AXM764: SFP+ transceiver 10GBASE-LR Lite, SFP+ single mode LC GBIC
•
Gigabit transceiver modules:
- AGM734: SFP transceiver 1000BASE-T, SFP copper RJ-45 GBIC
•
Direct attach cables:
-
AXC761: SFP+ 1 m (about 3.3 ft) direct attach cable
-
AXC763: SFP+ 3 m (about 10 ft) direct attach cable
For more information about NETGEAR SFP and SFP+ transceiver modules and cables,
visit netgear.com/business/products/switches/modules-accessories.
Multi-function Reset button
The switch provides a recessed, multi-function Reset button on the front panel.
Depending on how long you press the button (for details, see the following procedure),
this button lets you perform the following tasks:
•
Restart (power-cycle) the switch: The switch restarts. All saved settings are retained.
We recommend that you save the settings before you press the Reset button to
restart the switch.
Hardware Installation Guide18Hardware Overview
8-Port Multi-Gigabit/10G Ethernet (Ultra60 PoE++) Smart Managed Pro Switch with 2 SFP+ Ports
