Nighthawk AC1900 WiFi Cable Modem Router
Specify Network Settings User Manual41
MTU only if you are sure that it is necessary for your ISP connection. See Change
the MTU Size on page 28.
Disable SIP ALG. Some VoIP applications do not work well with the SIP ALG.
Selecting this check box to turn off the SIP ALG might help your VoIP devices to
create or accept a call through the modem router.
5. Click the Apply button.
Your changes are saved.
Set Up a Default DMZ Server
The default DMZ server feature is helpful when you are using some online games and
videoconferencing applications that are incompatible with Network Address Translation
(NAT). The modem router is programmed to recognize some of these applications and to
work correctly with them, but other applications might not function well. In some cases, one
local computer can run the application correctly if the IP address for that computer is entered
as the default DMZ server.
WARNING:
DMZ servers pose a security risk. A computer designated as the
default DMZ server loses much of the protection of the firewall and
is exposed to exploits from the Internet. If compromised, the DMZ
server computer can be used to attack other computers on your
network.
The modem router usually detects and discards incoming traffic from the Internet that is not a
response to one of your local computers or a service that you have configured in the Port
Forwarding/Port Triggering page. Instead of discarding this traffic, you can have the modem
router forward the traffic to one computer on your network. This computer is called the default
DMZ server.
To set up a default DMZ server:
1. Launch an Internet browser from a computer or wireless device that is connected to the
network.
2. Type http://www.routerlogin.net or http://www.routerlogin.com.
A login window opens.
3. Enter the user name and password.
The user name is admin. The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Setup > WAN Setup.

Table of Contents

Other manuals for NETGEAR Nighthawk C6900

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR Nighthawk C6900 and is the answer not in the manual?

NETGEAR Nighthawk C6900 Specifications

General IconGeneral
DOCSISDOCSIS 3.0
Channel Bonding24x8
Wireless Standard802.11a/b/g/n/ac
Wireless Frequency Bands2.4 GHz & 5 GHz
ModemCable Modem
Memory128 MB Flash and 256 MB RAM
Beamforming+Yes
Dynamic QoSYes
Smart ConnectYes
VPN SupportYes
Parental ControlsYes
Guest NetworkYes
WiFi Technology802.11ac
Maximum WiFi Speed1900 Mbps
Number of Ethernet Ports4 x Gigabit Ethernet ports
USB Ports1 x USB 2.0 port
Weight1.65 lbs
Processor1.0GHz dual-core processor
