Table 6. Technical specifications for the router (Continued)
DescriptionFeature
4.8 x 4.8 x 2.5 in. (121.92 x 121.92 x 63.5 mm)Dimensions
0.63 lb (285.76 g)Weight
0° to 40°C (32º to 104ºF)Operating temperature
90% maximum relative humidity, noncondensingOperating humidity
FCC Part 15, Subpart B, Class B
IECS-003, Class B
EN 55032, EN 55035, Class B
AS/NZS CISPR 32, Class B
Electromagnetic emissions
10BASE-T or 100BASE-TX or 1000BASE-T, RJ-45LAN
10BASE-T or 100BASE-TX or 1000BASE-T, RJ-45WAN
Maximum wireless signal rate complies with the IEEE 802.11
standard.
3
WiFi
2.4 GHz: Max 400 Mbps
5 GHz Front haul: Max 866 Mbps
5 GHz Back haul: Max 866 Mbps
Radio data rates
IEEE 802.11b/g/n 2.4 GHz–256 QAM support
IEEE 802.11 a/n/ac 5 GHz–256 QAM support
Data encoding standards
Limited by the amount of WiFi network traffic generated by
each node (typically 50–70 nodes)
2.4 GHz: 127
5 GHz (front haul): 127
Maximum number of
computers per wireless
network
2.4 GHz:
•
2.412–2.462 GHz (US)
•
2.412–2.472 GHz (Europe ETSI)
5 GHz:
•
5.18 GHz–5.24 GHz and 5.745 GHz–5.825 GHz (US)
•
5.18 GHz–5.24 GHz and 5.5 GHz–5.7 GHz (Europe)
•
5.26 GHz–5.32 GHz (Europe)
Operating frequency range
WPA-PSK [TKIP], WPA2-PSK [AES], WPA3-Personal802.11 security
3
Maximum wireless signal rate derived from IEEE Standard 802.11 specifications. Actual throughput can vary. Network
conditions and environmental factors, including volume of network traffic, building materials and construction, and
network overhead, lower actual data throughput rate.
User Manual128Supplemental Information
Nighthawk Mesh WiFi 6 System
