NETGEAR Nighthawk Mesh WiFi 6 System User Manual

Technical Specifications for Satellite Model MS60
The following table shows the technical specifications for the satellite.
Table 7. Technical specifications for the satellite
DescriptionFeature
TCP/IP, DHCP, Dynamic DNS, and UPnPData and routing protocols
North America: 120V, 60 Hz, input
UK, Australia: 240V, 50 Hz, input
Europe: 230V, 50 Hz, input
All regions (output): 12V, 1A DC output
Power adapter
4.8 x 4.8 x 2.5 in. (121.92 x 121.92 x 63.5 mm)Dimensions
0.63 lb (285.76 g)Weight
0° to 40°C (32º to 104ºF)Operating temperature
90% maximum relative humidity, noncondensingOperating humidity
FCC Part 15, Subpart B, Class B
IECS-003, Class B
EN 55032, EN 55035, Class B
AS/NZS CISPR 32, Class B
Electromagnetic emissions
Maximum wireless signal rate complies with the IEEE 802.11
standard.
4
WiFi
2.4 GHz: Max 400 Mbps
5 GHz Front haul: Max 866 Mbps
5 GHz Back haul: Max 866 Mbps
Radio data rates
IEEE 802.11b/g/n 2.4 GHz–256 QAM support
IEEE 802.11 a/n/ac 5 GHz–256 QAM support
Data encoding standards
Limited by the amount of WiFi network traffic generated by
each node (typically 50–70 nodes).
2.4 GHz: 127
5 GHz (front haul): 127
Maximum number of
computers per wireless
network
User Manual129Supplemental Information
Nighthawk Mesh WiFi 6 System

NETGEAR Nighthawk Mesh WiFi 6 System Specifications

General

WiFi Technology	WiFi 6 (802.11ax)
Antennas	Internal antennas
MU-MIMO	Yes
OFDMA	Yes
Security	WPA3
Beamforming	Yes
Backhaul	Dedicated WiFi backhaul
Parental Controls	Yes
Guest Network	Yes
App Support	Nighthawk App
Coverage	Up to 4, 500 sq. ft.
Speed	Up to 1.8Gbps
Number of Nodes	2 or 3 (depending on the specific model)
Bands	Dual-band
Ports	Gigabit Ethernet
Ethernet Ports	1 WAN and 3 LAN Gigabit Ethernet ports per node
Processor	Quad-core processor
Compatibility	Works with any internet service provider
