NETGEAR ProSafe GS510TP

Physical Description
13
NETGEAR GS510TP Smart Switch
LED Designations
Port LEDs
Table 1 describes the RJ-45 and SFP port LED designations. There are two LEDs for each
RJ-45 port.
Table 1. Port LEDs
LED Designation
Speed/Link/Activity SPD/Link/ACT LED:
• Off = No link is established on the port.
• Solid Green = A valid 1000 Mbps link is established on the port.
• Blinking Green = Packets transmission or reception is occurring on
the port at 1000 Mbps.
• Solid Yellow = A valid 10/100 Mbps link is established on the port.
• Blinking Yellow = Packets transmission or reception is occurring on
the port at 10/100 Mbps.
PoE Status PoE Status LED:
• Off = No PoE powered device (PD) connected.
• Solid Green = The PoE powered device is connected and the port is
supplying power successfully.
• Solid Yellow = Indicates one of the following failures resulted in
stopping power to that port:
Short circuit on PoE power circuit
PoE power demand exceeds power available
PoE current exceeds PD’s classification
Out of proper voltage band (44 ~ 57 VDC)
SFP Port Indicate LED • Off = No link is established on the port.
• Solid Green = A valid link is established on the port.
• Flashing Green = Packet transmission or reception is occurring on
the port.
Each SFP port has its own indication LED.
