NETGEAR R6050 User Manual

Hardware Setup
9
AC750 Wireless Dual Band Gigabit Router R6050
Hardware Features
Before you cable your router, take a moment to become familiar with the label and the front
and back panels. Pay particular attention to the LEDs on the front panel.
Front Panel
The router front panel has the status LEDs, buttons, and ports shown in the following figure.
2.4 GHz WiFi LED
Power LED
Internet LED
Ethernet ports 1–4 LEDs
USB port
WPS/FastLane
WiFi On/Off
5 GHz WiFi LED
and LED
button and LED
button and LED
Figure 2. Front panel
