NETGEAR WNDR4500v2 - Back Panel

Hardware Setup
11
N900 Wireless Dual Band Gigabit Router WNDR4500v2
Back Panel
The back panel has the connections shown in the following figure.
USB ports
LAN Ethernet ports 1–4
Internet port
Power On/Off button
Power
Reset button
Figure 3. Router, rear view
See Factory Settings on page 120 for information about restoring factory settings.
