Wireless-N 150 Router WNR1000v3 User Manual
Customizing Your Network Settings 4-9
v1.0, February 2010
In this case you must define a static route, telling your router that 134.177.0.0 should be accessed
through the ISDN router at 192.168.1.100.
In this example:
• The Destination IP Address and IP Subnet Mask fields specify that this static route applies
to all 134.177.x.x addresses.
• The Gateway IP Address field specifies that all traffic for these addresses should be
forwarded to the ISDN router at 192.168.1.100.
•A Metric value of 1 will work.
• Private is selected only as a precautionary security measure in case RIP is activated.
To add or edit a static route:
1. Select Static Routes under Advanced in the main menu. The Static Routes screen displays.
2. Click Add to expand the Static Routes screen.
3. In the Route Name field, enter a name for this static route. (This is for identification purposes
only.)
Figure 4-5
Figure 4-6
