Wireless-N 150 Router WNR1000v3 User Manual
Using Network Monitoring Tools 6-6
v1.0, February 2010
3. Click Show Statistics to display router usage statistics.
Table 6-3 describes the router statistics.
To change the polling frequency, enter a time in seconds in the Poll Interval field, and click
Set Interval.
To stop the polling entirely, click Stop.
Figure 6-3
Table 6-3. Router Statistics
Item Description
System Up Time The time elapsed since the router was last restarted.
Port The statistics for the WAN (Internet) and LAN (Ethernet) ports. For each port, the
screen displays the following:
Status The link status of the port.
TxPkts The number of packets transmitted on this port since reset.
RxPkts The number of packets received on this port since reset.
Collisions The number of collisions on this port since reset.
Tx B/s The current transmission (outbound) bandwidth used on the WAN and LAN ports
(the average bytes per second transmitted since reset). Tx B/s is the total bytes
transmitted divided by the system up time (in seconds).
Rx B/s The current reception (inbound) bandwidth used on the WAN and LAN ports (the
average bytes per second received since reset). Rx B/s is the total bytes received
divided by the system up time (in seconds).
Up Time The time elapsed since this port acquired the link.
Poll Interval The intervals at which the statistics are updated in this screen.
