Netis WF-2301 User Manual

150Mbps Wireless-N Outdoor AP User Manual
C:\Documents and Settings\admin>ping 192.168.1.1
Pinging 192.168.1.1 with 32 bytes of data:
Reply from 192.168.1.1: bytes=32 time=1ms TTL=64
Reply from 192.168.1.1: bytes=32 time=1ms TTL=64
Reply from 192.168.1.1: bytes=32 time=1ms TTL=64
Reply from 192.168.1.1: bytes=32 time=1ms TTL=64
Ping statistics for 192.168.1.1:
Packets: Sent = 4, Received = 4, Lost = 0 (0% loss),
Approximate round trip times in milli-seconds:
Minimum = 0ms, Maximum = 0ms, Average = 0ms
Then the connection between the AP and your computer has been successfully established.
If the computer fails to connect to the AP, the Command window will return the following:
C:\Documents and Settings\admin>ping 192.168.1.1
Pinging 192.168.1.1 with 32 bytes of data:
Request timed out.
Request timed out.
Request timed out.
Request timed out.
Ping statistics for 192.168.1.1:
Packets: Sent = 4, Received = 0, Lost = 4 (100% loss),
Verify your computer's network settings are correct and check the cable connection between the
AP and the computer.
In order to make the whole network operate successfully, it is necessary to configure the
150Mbps AP through your computer has a WEB browser installed. Please follow up the steps
listed below.

Netis WF-2301 Specifications

General

Brand	Netis
Model	WF-2301
Category	Wireless Access Point
Language	English
