TRS MIDI TYPE-A SUPPORT
The TRS MIDI Type-A connection is the ofcial standard adopted by the MIDI Association.
Nano Cortex's EXP/MIDI input will be compatible with any TRS MIDI cable that meets the
following requirements:
TIP: Data line (MIDI Din Pin 5).
RING: Voltage reference line (MIDI Din Pin 4).
SLEEVE: Shield line (MIDI Din Pin 2).
