2.5 Blend Refrigerants
The Ultima ID includes the “Blend ID” feature for determining the presence of EPA S.N.A.P
approved blend refrigerants. In the event that the Ultima ID determines that the refrigerant in the
system or cylinder is possibly a S.N.A.P. blend, the results will display as follows in Figures 13, 14,
and 15. Note that pressing the additional “MORE” button on the screen in Figure 14 will take the
user to the Blend Refrigerant screen shown in Figure 15. Note: This screen will vary based on the
test results.
FAIL
R12 92.7%
HELP MORE
RESULTS………….FAIL
R12 7.3%
R134 92.7%
R22 .0%
HC .0%
EXIT MORE PRINT
POSSIBLY ONE OF
THE FOLLOWING
BLEND
REFRIGERANTS
FREEZE 12
FREE ZONE OR
RB-276
DONE
Pressing the “DONE” button in Figure 15 will return the user to the screen shown in Figure 14.
2.6 Printing the Test Results
For units equipped with the optional built-in printer module, the test results can be printed by
selecting the “PRINT” button. After the print is complete, carefully tear off the printout and the
unit will return to the previous screen. Additional printouts may be made following the same
procedure. To exit the test, press the “EXIT” button. Figures 16, 17, 18 and 19, show sample
printouts for various test results.
Neutronics, Inc.
Refrigerant
Identifier
R134a = 100.0%
R12 = 0.0%
R22 = 0.0%
HC = 0.0%
AIR = 2.8%
Tested R134a….
Conclusion:
R134a: PASS<<<
______________
(Date)
______________
(Technician)
______________
______________
Neutronics, Inc.
Refrigerant
Identifier
R134a = 95.0%
R12 = 5.0%
R22 = 0.0%
HC = 0.0%
Tested R134a….
Conclusion:
R134a: FAIL<<<
______________
(Date)
______________
(Technician)
______________
______________
Neutronics, Inc.
Refrigerant
Identifier
R134a = 92.7%
R12 = 7.3%
R22 = 0.0%
HC = 0.0%
Tested R134a….
Conclusion:
R134a: FAIL<<<
Possible Blend:
FREEZE 12,
FREE ZONE, or
RB-276
______________
(Date)
______________
(Technician)
______________
______________
Neutronics, Inc.
Refrigerant
Identifier
R134a = 0.0%
R12 = 0.0%
R22 = 0.0%
HC = 0.0%
Tested R134a….
Conclusion:
R134a: FAIL<<<
EXCESSIVE AIR
______________
(Date)
______________
(Technician)
______________
______________
Figure 13 Figure 14 Figure 15
Figure 16
Figure 17 Figure 18 Figure 19
