Neutronics UltimaID User Manual

Manual Part Number:
5-06-7000-65-0
Manual File:
MN-A-0117 Rev. D
Revision Date: August 24, 2006 Page 3-6
3 MAINTENANCE & TROUBLESHOOTING
3.1 Setting the Elevation
During the initial power-up, the Ultima ID will indicate that the elevation has not been set. To set
the elevation, press the “Help” button on the “Ready to Air Cal” screen as shown in Section 2.2,
Figure 3. The screen will display several options as shown in Figure 20. Pressing the “SET” button
will display the options in Figure 21.
TO CHANGE
SETTINGS OR
REPLACE PAPER
ROLL PRESS SET
FOR OTHER HELP
PRESS HELP
SET HELP DONE
TO FEED IN A
NEW PAPER ROLL
PRESS FEED
PRESS SET TO
ADJ LCD CONTRAST
OR ELEVATION
SET FEED DONE
Press the “SET” button shown in Figure 21 to display the screen options shown in Figure 22.
Pressing the “ELEV” button will take you the elevation screen shown in Figure 23. Use the “UP” &
“DOWN” buttons to adjust the unit to the elevation in your area. Press the “SAVE” button when
finished to return to the help screen (Figure 20).
TO SET THE
ELEVATION PRESS
ELEV BUTTON
TO SET THE
LCD CONTRAST
PRESS CONT
ELEV CONT DONE
FEET 400
METERS 122
UP DOWN SAVE
3.2 Setting the LCD Contrast
The Ultima ID features an adjustable LCD contrast for use in varying light conditions. To adjust
the contrast, press the “HELP” button on the “Ready to Air Cal” screen as shown in Section 2.2,
Figure 3. The screen will display several options as shown in Figure 17. Pressing the “SET” button
will display the options in Figure 18.
Figure 20
Figure 21
Figure 22
Figure 23
