Manual Part Number:
5-06-7000-65-0
Manual File:
MN-A-0117 Rev. D
Revision Date: August 24, 2006 Page 4-10
4 APPENDICES
4.1 Spare Parts List
PART NUMBER DESCRIPTION
4-03-5004-07-0
R134a Tank Adapter Fitting
6-02-6000-09-0
R134a Sample Hose
6-02-6000-02-0
R12 Sample Hose
6-01-6001-08-0
Vehicle Power Cable
6-02-6000-08-1
Sample Filter (5 Pack)
6-02-6001-04-1
Battery Kit (Optional)
6-02-6001-04-0
Spare Battery
6-01-6001-10-0
Printer Upgrade (Factory Installation Only)
5-03-1000-08-0
Printer Paper Roll (Sold in Quantities of 10 Only)
5-06-7000-65-0
Operating Manual
4.2 Appendix B - Specifications
SAMPLE PARAMETERS:
Vapor only, oil-free, 300 psig (2 MPa) Maximum
DETECTED COMPOUNDS:
R12, R134a, R22, Hydrocarbons, Air
SENSOR TECHNOLOGY:
Non-Dispersive Infrared (NDIR)
REFRIGERANT SAMPLE SIZE:
0.3 ounces (8.5 grams) per sample
POWER:
9 – 15 VDC, 2 Amps Maximum
OPERATIONAL TEMPERATURE:
40-130
o
F
SAE J1771
If the refrigerant being tested is identified as contaminated,
any visual percentages displayed of CFC-12 (R-12) or HFC-
134a (R134a) outside the design certified value is
informational and may not be accurate.
This instrument has not been design certified for
contaminate detection of R124 or R142b.
