Manual Part Number:
5-06-7000-65-0
Manual File:
MN-A-0117 Rev. D
Revision Date: August 24, 2006 Page 3-7
TO CHANGE
SETTINGS OR
REPLACE PAPER
ROLL PRESS SET
FOR OTHER HELP
PRESS HELP
SET HELP DONE
TO FEED IN A
NEW PAPER ROLL
PRESS FEED
PRESS SET TO
ADJ LCD CONTRAST
OR ELEVATION
SET FEED DONE
Press the “SET” button shown in Figure 24 to display the screen options shown in Figure 25.
Pressing the “SET” button in Figure 25 will advance the display to Figure 26. Pressing the
“CONT” button will take you the contrast screen shown in Figure 27. Use the “UP” & “DOWN”
buttons to adjust the screen contrast for best viewing. Press the “SAVE” button when finished to
return to the help screen (Figure 24).
TO SET THE
ELEVATION PRESS
ELEV BUTTON
TO SET THE
LCD CONTRAST
PRESS CONT
ELEV CONT DONE
ADJUST CONTRAST
FROM 0 TO 80
SETTING
045
UP DOWN SAVE
3.3 Changing the Sample Filter
When inspecting the sample filter, look completely around the entire outside diameter of the white
filter element located inside of the clear plastic housing. Look for red spots or the beginnings of
discoloration on the white outside diameter of the element. Do not look into the round ends of the
white element for red spots or discoloration. The round ends of the filter may always appear red. If
red spots or discolorations are discovered, the sample filter requires replacement to prevent the
influx of particulate and oil mists into the instrument.
Obtain a replacement filter, part number 6-02-6000-08-0. Remove the existing filter from the
retaining clip of the instrument by pulling straight up and out. CAREFULLY remove the flexible,
black rubber tubing connections from both ends of the existing filter. DO NOT allow the tubes to
slip back into the internal portion of the case. Discard the existing filter in an environmentally
friendly manner.
Install the tube ends onto the barbs of the replacement filter, taking note to align the flow arrow of
the filter with the flow arrow of the instrument top panel. CAREFULLY slide the tubing back into
the internal portion of the instrument and seat the new filter into the retaining clip. Inspect the
sample hoses for signs of oil entrapment. Replacement of the sample filter usually requires
cleaning or replacement of the sample hoses.
Figure 24
Figure 25
Figure 26
Figure 27
