Dimensions & power Requirements 1
Input Voltage Range
90-240v AC Only
Switch-On surge current –
65A Peak @ 240v
>+26dBu @ 1kHz (<0.5% THD+N)
Typically +/- 0.15dB, 20Hz to 20kHz
Typically 0.002% @ 1kHz (measured at +20dBu, 10Hz to 80kHz filter)
<-85dBu (20Hz to 22kHz filter)
Typically -125dBu (20Hz to 20kHz)
Input Impedance ≈300Ω or ≈1.3kΩ (PAD out). Transformer coupled.
Gain 20dB to 70dB in 1dB steps.
Input Impedance ≈10kΩ Bridging (PAD out). Gain -20dB to +20dB in
1dB steps.
Input Impedance >650kΩ. Transformer-less Class A Gain 30dB to 60dB
in 1dB steps.
