Troubleshooting 1
No audio at the line output/s
Check all connections to the unit. For example, check that
corresponding inputs and outputs are routed to the same channel.
The front panel SIG led/s will light if any signal is detected.
Check the setting of the Gain control. Turn clockwise to increase the
Gain level.
Check the input source selection indicated on the front panel LEDs
matches the actual desired source.
Check that the FNT button is set to the desired option. This button
should be lit to select a front audio source.
No audio at the monitor or headphone output/s
Check the monitor source selection indicated on the front panel
LEDs matches the actual desired source. Press the HP LEVEL knob to
cycle through the options.
Check the MONITOR IN L & R XLR connections at the rear of the
unit.
Check the setting of the MONO button. In MONO mode, any audio
will be heard equally on left and right outputs, this will indicate an
issue on either side of the stereo signal.
Check the setting of the HP LEVEL control. Turn clockwise to increase
the output level.
No connection to the Dante Network
Make sure a CAT5/CAT6 cable is used to make the connection.
Check that the network switch is 1 gigabit and un-managed
Wait 25 seconds after making the physical connection.
Check that DANTE LED is lit on the front of the unit.
Check settings in Dante Controller
For more information on Dante Controller please visit
www.audinate.com
No USB Audio
If using PC, ensure the correct drivers are installed. Drivers can
be found at www.AMS-
Neve.com >1073OPXproductpage >supporting documentation.
Check the USB cable connection.
Open an au audio application on the connected computer. The
USB connection requires an active audio application to activate
the interface.
