Unit Connection Tables 1
External PSU Mains, fused @ 4 amps
IEC male
Preamplifier Microphone Inputs
(Front)
XLR 3-pin plug female
Preamplifier Microphone Inputs
(Rear)
25-way D-Type, Tascam convention
Preamplifier Line Inputs (Front)
¼" TRS Jack sockets
Preamplifier Line Inputs (Rear)
25-way D-Type, Tascam convention
Preamplifier DI inputs
¼" TRS Jack sockets
Preamplifier Outputs (Rear)
25-way D-Type, Tascam convention
Headphone Output
¼" TRS Jack socket
Monitor Inputs
XLR 3-pin plug Female
Monitor Outputs
XLR 3-pin plug Male
Comms
CAT 5e/6 ethernet socket
Line & DI Inputs & Headphone Output 1
All ¼’’ Line Inputs & Outputs on the unit have the same wiring
Tip
Hot
Ring
Cold
Sleeve
Ground
XLR Inputs & Outputs 1
All XLR Inputs & Outputs on the unit have the same wiring
Pin 2
Hot
Pin 3
Cold
Pin 1
Ground
