NewLine Vega Z Series User Manual

100
Specifications
Model
TT-6522Z TT-7522Z TT-8622Z
Display
Backlight LED
Display Area 56.24 in x 31.63 in/
1432 x 807mm
64.97 in x 36.55 in/
1652 x 930mm
74.69 in x 42.05 in/
1893 x 1069mm
Active Screen Size 65 inch 75 inch 86 inch
Display Ratio 16:9
Resolution 3840 x 2160 Pixel
Display Colors 8 bit+FRC, 1.07 billion
colors
8 bit+FRC, 1.07 billion
colors
10 bit, 1.07 billion
colors
Brightness ≥ 400 cd/m
2
Contrast ≥5000:1 ≥5000:1 ≥5000:1
Response Time ≤ 8 ms
Life Time ≥50000 h (Min.)
Speaker
Speaker Position Forward
Max. Power
Output
2 x 15 W
Microphone
Type 3.5 mm interface
Electrical
Power
Consumption
Maximum ≤ 400 W
Standby Mode ≤ 0.5 W
Maximum ≤ 450 W
Standby Mode ≤ 0.5 W
Maximum ≤ 500 W
Standby Mode ≤ 0.5 W
Working Voltage AC 100 V – 240 V, 50 Hz / 60 Hz
Touch
Touch Surface Anti-glare tempered glass
