17
Getting Started
3
3.4 CONNECTING SENSOR INPUTS (Continued)
Figure 3-10. DC Current Input Connections with Internal Excitation
Figure 3-11. DC Current Input Connections with External Excitation
TB2
1234
5678
(+)
(-)
+
-
4-20mA
Transmitter
-E +E +20mA N/C
+24V +S -S N/C
EXTERNAL
SUPPLY
TB2
1234
5678
(+)
(-)
-E +E +20mA N/C
+24V +S -S N/C
4-20mA
Transmitter
