SECTION 8. SPECIFICATIONS (Continued)
ALARM OUTPUTS (if applicable)
2 Form "C" on/off relays. Configurable for latched and
unlatched by software.
Max current: 5 AMPS, resistive load
Max voltage: 250 Vac or 30 Vdc
ANALOG OUTPUT (if applicable)
Signal Type: Current or voltage
Signal Level: Current: 10 V max compliance at 20 mA output
Voltage: 20 mA max for 0-10 V output
Function: May be assigned to a display range or proportional
control output with Setpoint #1 when used as a control
output.
Linearity: 0.2%
Step Response Time: 2 - 3 seconds to 99% of the final value
ISOLATED ANALOG OUTPUT (TB5, if applicable)
Same as non-isolated analog output except isolated.
Signal Type: Current or voltage
Signal Level: Current: 10 V max compliance at 20 mA output
Voltage: 20 mA max for 0-10 V output
Function: May be assigned to a display range or proportional
control output with Setpoint #1 when used as a control
output.
Linearity: 0.2%
Step Response Time: 2 - 3 seconds to 99% of the final value
Isolation 130 Vrms working voltage, 1000 V/60sec Dielectric test
• Only one analog output is available on each unit and it must be factory
installed.
