Newport Electronics INFCP-B Series User Manual

4
Configuring The Meter
36
4.10.2 Selecting Analog Output as Current or Voltage
1. Press the MENU button until it shows OT.CF, then press the ∂TARE button twice.
or
Press the ∂TARE button from 0.1 .
The meter shows one of the following:
• O.2=C (Analog output = current) (Default)
• O.2=V (Analog output = voltage)
2. Press the ßMAX button to toggle between available choices.
3.
Press the ∂TARE button to select analog output or proportional control or press the
MENU button to store your selection and enter OT.S.O (Output Scale and Offset).
4.10.3 Selecting Analog Output or Proportional Control
Use this section to select if the meter will transmit an analog signal
proportional to the display readings, or proportional to the error signal between
the display reading and Setpoint 1.
Proportional Control Analog Option is not available for models without Relay Option.
1. Press the MENU button until it shows OT.CF , then press the ∂TARE button twice.
or
Press the ∂TARE button from 0.2 .
The meter shows one of the following:
• O.3=A (Analog output is regular) (Default)
• O.3=P (Analog output is proportional)
2. Press the ßMAX button to toggle between available choices.
Note
☞
