Configuring The Meter
4
4.4.1 Enabling or Disabling the Front-Panel Tare
To enable or disable the front-panel tare, follow these steps:
1. Press the MENU button until RD.CF displays.
2. Press the ∂TARE button. The meter shows one of the following:
• R.1=T (Tare enabled) (Default)
• R.1=N (Tare disabled)
3. Press the ßMAX button to view last stored selection. Press the ßMAX button to
toggle between selections.
4. Press the ∂TARE button to select input resolution or press the MENU button to
store your selections. STRD momentarily displays, followed by COLR menu.
4.4.2 Setting Input Resolution
To set the input resolution of your meter, follow these steps:
1. Press the MENU button until RD.CF displays, then press the ∂TARE button twice.
or
Press the ∂TARE button from R.1 .
One of the following displays (default is R.2=4 ):
R.2=4 = 10 µV for Unipolar inputs. 25 µV for Bipolar inputs
R.2=0 = 1 µV for Unipolar inputs. 5 µV for Bipolar inputs.
R.2=1 = 2 µV for Unipolar inputs. 10 µV for Bipolar inputs
R.2=2 = 3 µV for Unipolar inputs. 15 µV for Bipolar inputs.
R.2=3 = 5 µV for Unipolar inputs. 25 µV for Bipolar inputs
Example: 3 µV resolution means that if you input 0-30 mV, at 30 mV the display shows
9999 .
2. Press the ßMAX button to scroll through available selections.
3. Press the ∂TARE button to display the filtered/unfiltered signal input or press the
MENU button to store your selections. STRD momentarily displays, followed by
COLR menu.
