Configuring The Meter
4242
4.13 USING OUTPUT SCALE AND OFFSET OT.S.O (Continued)
11. Press the ∂TARE button. The meter shows last previously stored 4-digit number
(-1999 through 9999) displays with flashing 4th digit.
12. Press the ßMAX button to change the value of the flashing digit. If you continue
to press the ßMAX button, the flashing digit's value continues to change.
13. Press the ∂TARE button to scroll to the next digit.
14.
Press the MENU button to store your selection. The meter shows OUT.2 (Output 2).
This analog signal should correspond to your Read 2 display.
15. Press the ∂TARE button. The meter shows selected output.
If you select O.2=V for voltage, the maximum signal you may select is 10.00
for an 0-10 Vdc signal output. If you select O.2=C for current, the maximum
signal you may select is 20.00 for a 0-20 or 4-20 mA DC signal output.
16. Press the ßMAX button to change the value of the flashing digit. If you continue to
press the ßMAX button, the flashing digit's value continues to change.
17. Press the ∂TARE button to scroll to the next digit.
18. Press the MENU button to store your selection. The meter momentarily shows
STRD , followed by LK.CF (Lockout Configuration).
WARNING: If the meter displays all flashing values on any item, the value
has overflowed. Press the ßMAX button to start new values.
