Appendix C – Technical
Specifications
User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
version 3.2
102
SHAPING THE FUTURE SATELLITE OF COMMUNICATIONS
APPENDIX C – TECHNICAL SPECIFICATIONS
Input interface
ASI/SPI interface (default):
• 2 selectable ASI input on BNC (F) - 50 ohms (coax);
• 2 selectable ASI output (loop through) on BNC (F) - 50 ohms (coax);
• SPI on 25 pin sub-D connector;
• Optical ASI on ST (optional);
• 188 or 204 byte mode;
• Encryption (optional):
- BISS (single program): mode 0,1, E : up to 54 Mbit/s;
- BISSM (multiple program): mode 0,1,E :up to 100 Mbit/s.
• Rate adapter.
Modulation
Supported modulation schemes and FEC
• DVB-S/DSNG:
Outer/Inner FEC: Reed Solomon /Viterbi;
ModCods:
- QPSK: 1/2, 2/3, 3/4, 5/6, 7/8;
- 8PSK: 2/3, 5/6, 8/9;
- 16QAM: 3/4, 7/8.
• DVB-S2:
Outer/Inner FEC: BCH/ LDPC;
ModCods:
- QPSK: 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10;
- 8PSK: 3/5, 2/3, 3/4, 5/6, 8/9, 9/10;
- 16APSK: 2/3, 3/4, 4/5, 5/6, 8/9, 9/10;
- 32APSK: 3/4, 4/5, 5/6, 8/9, 9/10.
Baud rate Range
• DVB-S2:
- QPSK/8PSK0,05 – 45 Mbaud;
- 16APSK/32APSK 0,05 – 33 Mbaud.
• DVB-S/DSNG:
- QPSK/8PSK/16QAM 0.05-45 Mbaud.
