Options
AZ 110 Broadcast Satellite Modulator
Ordering
n°
Default
Configuration
DVB Modulator, SNMP
Modulation & Baud rate: DVB-S 5Mbaud
Input interface: ASI interface + Rate adaptor
Output interface: L-band ( 950-1750 MHz)
AZ110
Configuration
Options
Category
Max. 1 option per
category
Input Interface
ASI
Default
ASI + Optical ASI
AG-02
Output Interface
L-band (950-1750 MHz)
Default
IF (50-180 MHz)
AA-02
L-band + 10MHz for BUC
AA-03
L-band + 10MHz + 24Vdc for BUC
AA-12
L-band + 10MHz + 48Vdc for BUC
AA-13
Extended L-band ( 950-2150 MHz)
AA-18
IF+ L-band
AA-06
L + C-band (5,85-7,05 GHz)
AA-14
L+ Ku-band (12,75-13,25 GHz )
AA-08
L+ Ku-band (13,75-14,50 GHz)
AA-09
L + DBS-band (17,30-18,10 GHz)
AA-10
L + DBS-band (17,60-18,40 GHz)
AA-11
Additional
Options
Max. 1 option per
category
10MHz reference
In/Out
High stability
GR-01
Very high stability
GR-02
Predistortion
Equalink *
AC-01
Encryption
BISS (**)
AD-01
BISSM (**)
AD-02
Security
AES 64 bit encryption *
AS-01
Input frame
Baseband frame (only with Ethernet interface)
AV-01
