User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
version 3.2
62
SHAPING THE FUTURE SATELLITE OF COMMUNICATIONS
6.4.2 Parameters in the GUI
6.4.2.1 Parameter Interface Types
The GUI contains different types of parameter dialog boxes to set up all
parameters of a configuration.
Dialog box
type
Example
Drop-down
list box
Data field
Checkbox
Table
Functional
group
Table 9 – Parameter Interface Type Examples
If you want to change one of the parameters in a functional group
check and/or adjust all parameters in that group.
