6.3.1 Banner
The banner contains an editable text field right of the product name. The user can
use this text field to assign a unique identifier to the device. Double-click this text to
edit the content.
The text displayed in the editable text field of the banner is the
same as the screensaver message.
6.3.2 Central Stage Window
The central stage window contains by default three tabs:
• Overview;
• Tree;
• Trending Graphs.
Figure 18 – Default Tabs Central Stage Window
6.3.2.1 Overview Tab
The Overview tab contains a schematic representation of the signal flow in the
device. The signal passes different functional blocks and each block contains a
function name, basic settings and counters. The blocks are connected with arrows
that illustrate the process flow.
