About this manual
User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
version 3.2
xiv
SHAPING THE FUTURE SATELLITE OF COMMUNICATIONS
Modulation &
Baud rate
DVB-S Q/8PSK, 16QAM 5Mbaud
Default
DVB-S Q/8PSK, 16QAM 15Mbaud*
AB-02
DVB-S Q/8PSK, 16QAM 30Mbaud*
AB-03
DVB-S Q/8PSK, 16QAM 45Mbaud*
AB-04
DVB-S/S2 QPSK 5Mbaud*
AB-25
DVB-S/S2 QPSK 15Mbaud*
AB-26
DVB-S/S2 QPSK 30Mbaud*
AB-27
DVB-S/S2 QPSK 45Mbaud* AB-28
DVB-S/S2 Q/8PSK 5Mbaud*
AB-05
DVB-S/S2 Q/8PSK 15Mbaud*
AB-06
DVB-S/S2 Q/8PSK 30Mbaud*
AB-07
DVB-S/S2 Q/8PSK 45Mbaud*
AB-08
DVB-S/S2 Q/8PSK, 16QAM, 16APSK 5Mbaud*
AB-09
DVB-S/S2 Q/8PSK, 16QAM, 16APSK 15Mbaud*
AB-10
DVB-S/S2 Q/8PSK, 16QAM, 16APSK 30Mbaud*
AB-11
DVB-S/S2 Q/8PSK, 16QAM, 16APSK 45Mbaud*
AB-12
DVB-S/S2 Q/8PSK, 16QAM, 16/32APSK 5Mbaud*
AB-13
DVB-S/S2 Q/8PSK, 16QAM, 16/32APSK 15Mbaud*
AB-14
DVB-S/S2 Q/8PSK, 16QAM, 16/32APSK 30Mbaud*
AB-15
DVB-S/S2 Q/8PSK, 16QAM, 16/32APSK 45Mbaud*
AB-16
Additional
Options
Category
Max. 1 option per
category
10MHz reference
In/Out
High stability
GR-01
Very high stability
GR-02
Predistortion
Equalink *
AC-01
Encryption
BISS (**)
AD-01
BISSM (**)
AD-02
Security
AES 64 bit encryption *
AG-01
Input frame
Baseband frame (only with Ethernet interface)
AV-01
Services
Category
Max. 1 option per
category
Assistance
Care Pack Basic
GA-06
Care Pack Extended
GA-07
(*) upgrade via license key (**) Not available with
DualFlow options
Option AA-06 IF+Lband: Switching the IF frequency from 70 to 140MHz or
140MHz to 70MHz has no impact on the L-band frequency.
