Appendix C – Technical
Specifications
User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
version 3.2
104
SHAPING THE FUTURE SATELLITE OF COMMUNICATIONS
• Spurious: better than -65 dBc/4 kHz @ -10 dBm level and > 256 kbaud.
RF band (optional)
• Connector SMA (F), 50 ohms;
• Return loss > 12 dB;
• Frequencies:
- 5.85-7.05 GHz;
- 12.75-13.25 GHz;
- 13.75-14.5 GHz.
• Level -35/-7 dBm (+/- 3dB);
• Frequencies:
- 17.30-18.10 GHz;
- 17.60-18.40 GHz;
• Level -25/+3 dBm (+/- 3dB).
L-band monitoring output (default)
• Connector SMA (F), 50 ohms;
• Return loss > 7 dB;
• Level -45 dBm;
Frequency default: identical to L-band output
with options: AA-02 / AA-06: 1080 MHz.
BUC power and reference frequency (optional)
• Max. current 3A;
• Voltage 12V, 24V, 48V;
• Frequency 10MHz;
• Stability ±5x10-8 over 0°C to 65°C.
10 MHz reference input / output (optional)
• Connector BNC (F) – 50 ohms;
• Input level -3dbm up to 7dBm;
• Output level +7dBm;
• Internal Reference frequency.
High Stability (optional)
• Stability: ±5x10 over 0°C to 70°C;
• Ageing: ± 15 ppb/day ± 300 ppb/year.
