Physical Description
User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
version 3.2
34
SHAPING THE FUTURE SATELLITE OF COMMUNICATIONS
Option Back Panel Combination
Connectors Not Used
BP-<number>/<connector>,<connector>
AA-10 BP 01
BP 02
BP 07
BP 01/3,4
BP 02/1,3,4
AA-11 BP 01
BP 02
BP 07
BP 01/3,4
BP 02/1,3,4
AA-18 BP 01
BP 02
BP 01/3,4
BP 02/1
For example:
When option AA-12 is ordered the following back panels are used to assemble the
device:
Figure 11 - Example Back Panel Combination
