Page #100 background image
PSM1700 PsimetriQ user manual
A-2
Power meter adaptors
The power meter adaptors allow easy and safe connection
of the PsimetriQ to a mains appliance under test to
measure the power or harmonics.
The appliance under test plugs into an IEC mains outlet on
the adaptor, which contains an isolating voltage
transformer and current transformer with precision low
resistance shunt.
The adaptor is fitted with an IEC mains inlet for use with
an appropriate mains lead.
When the adaptor is plugged into the mains and the mains
switched on, the appliance is energised and PsimetriQ can
be used to measure the power or harmonics.
Leave the PsimetriQ generator off (OUT menu) so that it
will synchronise to the mains frequency.
Part numbers
500-058
IEC 10A power meter adaptor
