PSM1700 PsimetriQ user manual
11-5
11.1 Frequency response analyser specification
Frequency response (gain/phase) analyser
frequency
10uHz to1MHz (own generator)
20mHz to 500kHz (external source)
max input
100V peak 50Vrms
input ranges
100V, 30V, 10V, 3V, 1V, 300mV,
100mV, 30mV, 10mV
ranging
full auto, up only, or manual
input impedance
1M // 30pF (exc. leads)
gain accuracy
0.02 dB < 1kHz
0.05 dB < 10kHz
0.1 dB + 0.001 dB/kHz < 1MHz
phase accuracy
0.02 < 10kHz
0.02 + 0.003/kHz < 1MHz
sweep step rate
1/20s, 1/3s or 2.5s (approx.)
Conditions:
23ºC +/- 5ºC ambient temperature
instrument allowed to warm up for 30 minutes
ac+dc coupling
autoranging or manual ranging 1/3 range
