Page #85 background imageLoading...
Page #85 background image
PSM1700 PsimetriQ user manual
15-4
15.1 Harmonic analyser specification
Harmonic analyser
fundamental
frequency
100uHz to 500kHz (own generator)
20mHz to 500kHz (external source)
harmonic
frequency
10uHz to 1MHz
measurement type
multiple DFT analysis
measurements
single harmonic, differential thd, thd
by series of harmonics
max harmonic
64
max input
100V peak, 50V rms
input ranges
100V, 30V, 10V, 3V, 1V, 300mV,
100mV, 30mV, 10mV
ranging
full auto, up only, or manual
input impedance
1M // 30pF (exc. leads)
magnitude
accuracy
0.1% of fundamental + 0.01mV +
accuracy of fundamental
sweep step rate
1/20s, 1/3s or 2.5s (approx.)
Conditions:
23ºC +/- 5ºC ambient temperature
instrument allowed to warm up for 30 minutes
ac+dc coupling
autoranging or manual ranging 1/3 range
