PSM1700 PsimetriQ user manual
14-7
14.1 LCR meter specification
LCR meter
frequency
10uHz to 1MHz (own generator)
20mHz to 500kHz (external source)
measurement type
DFT analysis
measurements
L, C, R (ac), Q, tan, impedance,
phase, admittance
series or parallel circuit
conditions
auto, or manual
display
numeric values
table of sweep results
graph of any measurement
ranges
(with external
shunt)
100pF to 100uF
1H to 100H
1 to 1M
ranges
(with active head)
10pF to 1000uF
100nH to 10kH
10m to 100M
basic accuracy
0.1% + Tolerance of Shunt
sweep step rate
1/20s, 1/3s or 2.5s (approx.)
Conditions:
23ºC +/- 5ºC ambient temperature
instrument allowed to warm up for 30 minutes
ac+dc coupling
autoranging or manual ranging  1/3 range
both signals < 10V peak
