PSM1700 PsimetriQ user manual
16-13
Transformer analyser specification
Transformer analyser
frequency
10uHz to 1MHz (own generator)
20mHz to 500kHz (external source)
measurement type
DFT analysis, true rms as appropriate
measurements
turns ratio
turns
inductance
leakage inductance
ac resistance
dc resistance
interwinding capacitance
insertion loss
return loss
harmonics
thd
longitudinal balance
conditions
auto, or manual
display
numeric values
table of sweep results
graph of any measurement
accuracy
refer to other functions
sweep capability
all ac functions
sweep step rate
1/20s, 1/3s or 2.5s (approx.)
