PARTS LIST
NXAMP4x1
OVERALL ASSEMBLY 1/2.................................................................... 2
2/2.................................................................... 4
PA UNIT .................................................................................................. 6
LCD ASSEMBLY .................................................................................... 8
LOCATIONS OF HEAT SINK UNITS ..................................................... 9
HEAT SINK UNIT L100 ........................................................................ 10
HEAT SINK UNIT L100 ........................................................................ 11
HEAT SINK UNIT L60 .......................................................................... 12
HEAT SINK UNIT L60 .......................................................................... 13
HEAT SINK UNIT L50 .......................................................................... 14
HEAT SINK UNIT OSH ........................................................................ 15
ELECTRICAL PARTS ............................................................................ 16
■ CONTENTS
■ WARNING
Components having special characteristics are marked and must be replaced with parts having
specification equal to those originally installed.
• The numbers “QTY” show quantities for each unit.
• The parts with “--” in “PART NO.” are not available as spare parts.
• This mark “ } ” in the REMARKS column means these parts are interchangeable.
• The second letter of the shaded ( ) part number is O, not zero.
• The second letter of the shaded ( ) part number is I, not one.
Notes: DESTINATION ABBREVIATIONS
CHN : Chinese model U : U.S.A. model
