In Vehicle Installation (contd.)
7 Refit Cable Lock
The cable lock can now be refitted by firstly inserting the tang fully and then rotating the cable
lock until it engages fully around the power cable and then clicks in to place in the mount.
The cable clamp can be secured to the mount to prevent un-authorised removal, see pages
31 for further details.
8 Refit Camera to Mount
Offer the mount to the camera to engage the locking pins and then slide the mount away
from the camera lens to engage the mount connections fully.
7
8
9
9 Attach the Rear Cam Connector Cable to the Dash Cam
Plug the USB-C end of the 6.5m connector cable into the port at the rear of the Dash Cam.
20
To Next Page
