Back:
6. Wi-Fi button
Press and hold the Wi-Fi button for 2 seconds to turn on the Dash Cam's Wi-Fi function, a
beep sound will also be when ‘Sounds’ are enabled.
Once turned on, the button will flash slowly blue in colour, awaiting a connection from a
smartphone / tablet etc.
Once a device has been successfully connected the button will become solid blue.
If a connection is not established within 2 minutes, then the Wi-Fi function will turn off
automatically and the blue flashing light will extinguish.
7. Red LED indicator
The red LED has three functions, as described below:
Power
The LED will be illuminate when power is connected to the Dash Cam.
Recording
During recording the red LED will flash.
Firmware update
During the firmware updating process, then red LED will flicker.
87
3 6
5
4
PARTS & CONTROLS (CONTD.)
9
