19NIBE BA-SVM 10-200
Connections
General information
NIBE SPLIT can be connected in several different
ways. For more information about connections, go to
the website www.nibe.eu.
AMS 10-6 AMS 10-8 AMS 10-12
Maximum pressure, climate system 0,3 MPa (3 Bar)
Highest recommended flow/return temperature at dimensioned
outdoor temperature.
55/45 °C
Max. temperature in the unit BA-SVM 10-200 +65 °C
Maximum hot water temperature +65 °C
Minimum temperature ext. operation of the unit -20 °C
Minimum temperature ext. cooling operation +10 °C
Max. supply temperature, compressor +58 °C
Min. cooling supply temperature +7 °C
Max. cooling supply temperature +25 °C
Minimum volume, climate system during heating/cooling* 50 l 80 l 100 l
Max. flow, climate system 0,29 l/s 0,38 l/s 0,57 l/s
Min. flow, climate system 0,09 l/s 0,12 l/s 0,15 l/s
Min. flow, cooling system 0,11 l/s 0,16 l/s 0,20 l/s
* Refers to volume associated with undisturbed flow
Section 4 | Pipe connections
