62 NIBE BA-SVM 10-200
10 Service
Service operations
CAUTION
Servicing should only be carried out by persons with
the necessary technical expertise.
When replacing components of BA-SVM10-200, use
only original spare parts.
CAUTION
Switch (SF1) must not be put into „ ” mode be-
fore the installation is filled with water. The circulation
pump in the heat pump can be damaged.
Emergency mode
Temperature sensor resistance table
Emergency mode is used in case of operational inter-
ference and during servicing. Hot water is not pro-
duced in emergency mode.
Emergency mode is activated by setting switch (SF1)
in “ ” mode. This means that:
• The status lamp lights up yellow.
• The display is not lit and the control computer is
not connected.
• Hot water is not produced.
• The compressors are switched off. Feed pump
(EB101-GP12) and feed pump (EB102-GP12) (if in-
stalled) are running.
• Accessory is switched off.
• The heating medium pump is active.
• The emergency mode relay (K1) is active.
• Electric module available power - 3kW.
The external additional heat is active if it is connected
to the emergency mode relay (K1, terminal block X1).
Ensure that the heating medium flows through the ex-
ternal additional heat.
Temperature
(ºC)
Resistance
(kOm)
Voltage
(VDC)
-40 351.0 3.256
-35 251.6 3.240
-30 182.5 3.218
-25 133.8 3.189
-20 99.22 3.150
-15 74.32 3.105
-10 56.20 3.047
-5 42.89 2.976
0 33.02 2.889
5 25.61 2.789
10 20.02 2.673
15 15.77 2.541
20 12.51 2.399
25 10.00 2.245
30 8.045 2.083
35 6.514 1.916
40 5.306 1.752
45 4.348 1.587
50 3.583 1.426
55 2.968 1.278
60 2.467 1.136
65 2.068 1.007
70 1.739 0.891
75 1.469 0.758
80 1.246 0.691
85 1.061 0.607
90 0.908 0.533
95 0.779 0.469
100 0.672 0.414
Section 10 | Service operations
