71NIBE BA-SVM 10-200 Section 13 | Technical data
Technical data
*If the length of the refrigerant pipes exceeds 15 m, extra refrigerant must be added in the amount of 0.06 kg/m.
Outdoor unit Unit AMS 10-6 AMS 10-8 AMS 10-12
Starting current A 5
Compressor - Twin Rotary
Max. nominal fan performance
(heating)
m
3
/h 2 530 3 000 4 380
Fan power W 50 86
Defrosting - Reverse cycle
Hot water tank drip tray W Integrated 110 Integrated 100 Integrated 120
High pressure critical value MPa (bar) 4.15 (41.5)
Low pressure switch-off value (15 s) MPa (bar) 0.079 MPa (0.79)
Height mm 640 750 845
Width mm 800 780 (+67 valve cover) 970
Depth mm 290 640 (+110 base rail) 370 (+80 base rail)
Weight kg 46 60 74
Colour (two layers of powder coating) - Dark grey
Refrigerant amount kg 1. 5 2.55 2.90
Max. length of refrigerant pipe one-way m 30*
Refrigerant pipe dimensions -
Gas pipe:
ext. diameter 12.7 (1/2”)
Liquid line:
ext. diameter 6.35 (1/4”)
Gas pipe: ext. diameter 15.88 (5/8”)
Liquid line: ext. diameter 9.53 (3/8”)
Optional pipe connections - Right-hand side Bottom / right-hand side/ back
Part no. - 064 205 064 033 064 110
Type of product Unit BA-SVM 10-200/6 E/EM/R BA-SVM 10-200/12 E/EM/R
Height mm 1590
Required ceiling height mm 2100
Width mm 600
Depth mm 610
Weight kg
161
(124 - ONLY BA-SVM 10-200/6 R)
165
(128 - ONLY BA-SVM 10-200/12 R)
Maximum operating pressure of central heating system. bar 3
Maximum hot water pressure bar 10
Hot water tank volume l 180
Maximum operating temperature of central heating °C 65
Maximum hot water temperature °C 65
Low-energy circulation pump clim. sys. - Ye s
Safety valve. climate system - Yes, in the safety assembly
Expansion vessel l 10
Additional heat kW 4.5 (230V) / 9 (400V)
Rated voltage V 1x230 / 3x400
Hot water tank corrosion protection - Enamel + titanium anode (E, E EM) / Stainless Steel (R)
Maximum hot water capacity in accordance with EN16147 - 230 litres. 40°C
Energy class (in accordance with ErP. at supply temp.
55°C) applies to package AMS 10-12 + BA-SVM 10-200/12
and AMS 10-6 + BA-SVM 10-200/6
- A++
Efficiency class / Load profile (hot water) - A/XL
