72 NIBE BA-SVM 10-200
Max. operating current and recommended fuse rating
for 3x400 V connection
Unit
BA-SVM
10-200/6
E/EM/R
+ AMS 10-6
BA-SVM
10-200/12 E/EM/R
+ AMS 10-8
BA-SVM
10-200/12 E/EM/R
+ AMS 10-12
Max. operating current, compressor A 16 16 20
Max. operating current of heat pump including 3 kW
immersion heater, compressor running and contactor
K1 connected (recommended fuse rating)
A 16 (16) 16 (16) 20 (20)
Max. operating current of heat pump including 6 kW
immersion heater, compressor running and contactor
K1+K2 connected (recommended fuse rating)
A 16 (16) 16 (16) 20 (20)
Max. operating current of heat pump including 9 kW
immersion heater, compressor running and contactor
K1+K2+K3 connected (recommended fuse rating)
A 20 (20) 20 (20) 20 (20)
Max. operating current of 9 kW immersion heater,
contactor K1+K2+K3 connected, compressor not
running (recommended fuse rating)
A 20 (20) 20 (20) 20 (20)
Max. operating current and recommended fuse
rating for 1x230 V connection
Unit
BA-SVM
10-200/6
E/EM/R
+ AMS 10-6
BA-SVM
10-200/12 E/EM/R
+ AMS 10-8
BA-SVM
10-200/12 E/EM/R
+ AMS 10-12
Max. operating current. compressor A 16 16 20
Max. operating current of heat pump including 1.5
kW immersion heater. compressor running and con-
tactor K1 connected (recommended fuse rating)
A 22.5 (25) 22.5 (25) 26.5 (25)
Max. operating current of heat pump including 3 kW
immersion heater. compressor running and contactor
K1+K2 connected (recommended fuse rating)
A 29 (32) 29 (32) 33 (32)
Max. operating current of heat pump including 4.5 kW
immersion heater. compressor running and contactor
K1+K2+K3 connected (recommended fuse rating)
A 35.5 (32) 35.5 (32) 39.5 (40)
Max. operating current of 4.5 kW immersion heater.
contactor K1+K2+K3 connected. compressor not
running (recommended fuse rating)
A 19.5 (20) 19.5 (20) 19.5 (20)
Section 13 | Technical data
