38 NIBE BA-SVM 10-200
OPERATION
SELECTING MENU
SELECTING OPTIONS
Setting a value
To move the cursor, turn the control knob
to the left or the right. The selected posi-
tion is white and/or has a highlighted tab.
To advance in the menu system, choose a main menu
by selecting it and then pressing the OK button. A
new window then opens with submenus.
Choose one of the submenus by selecting it and then
pressing the OK button.
To set a value:
1. Select the value you want to set using the
control knob.
2. Press the OK button. The background of
the value turns green, which means that
you have accessed the setting mode.
3. Turn the control knob to the right to in-
crease the value and to the left to reduce
the value.
4. Press the OK button to confi rm the value
you have set. To change and return to the
original value, press the Back button.
In an options menu the current selected op-
tion is indicated by a green tick.
To choose another option
1. Select the applicable option. One of the
options is pre-selected (white).
2. Press the OK button to confi rm the se-
lected option. The selected option has a
green tick.
INDOOR CLIMATE
MY SYSTEM INFO
HOT WATER
temperature
INDOOR CLIMATE 1
advanced
scheduling
o
Marked main menu
Menu number – marked sub menu Name and menu number – main menu
Symbol – main
menu
Status information – sub menus
Name – sub menusSymbols – sub menus
economy
comfort mode
2.2
normal
luxury
smart control
time & date
4.4
time
day
year
month
24 h
12 h
date
Values to be changed
Section 8 | Control - Introduction
