Nibe BA-SVM 10-200 Series User Manual

52 NIBE BA-SVM 10-200
Menu 3.4 - Alarm log
Menu 4 - MY SYSTEM
Menu 4.1 - Additional functions
Menu 4.1.3 - Internet
Menu 4.1.8 - Smart Energy Source™
Menu 4.2 - Operating mode
Menu 3.5 - Room temp. log
To facilitate fault-finding, the heat pump’s operating
status at the time of the alarm is recorded here. You
can see information for the 10 most recent alarms. To
view operating status in the event of an alarm, select
the alarm and press the OK button.
Information about the controller’s operation and set-
tings can be viewed in this menu. Status information
for the relevant menu can be found on the display to
the right of the menus.
Settings for any additional functions installed in BA-
SVM 10-200 can be changed in the submenus.
You can configure BA-SVM 10-200 unit internet con-
nection in this menu. For more information select "
?
".
The function prioritises how / to what extent each
docked energy source will be used. Here you can
choose if the system is to use the energy source that
is cheapest at the time. You can also choose if the sys-
tem should use the energy source that is most carbon
neutral at the given time. For more information select
"
?
".
The heat pump operating mode is normally set to
“auto”. The heat pump can also be set to “add. heat
only”, but only when using the additional heat, or
“manual” and select the available functions yourself.
Change the operating mode by selecting the desired
mode and pressing the OK button. When an operating
mode is selected, the available functions of the heat
pump (crossed out = not available) and options will
be displayed on the right. To choose which functions
should be available or not available, select the function
using the control knob and press the OK button. For
more information select "
?
".
Here you can see the average indoor temp. - temp. log
week by week over the past year. The dotted line indi-
cates the annual average temperature.
The average indoor temperature is only shown if a
room temperature sensor/room display unit is in-
stalled.
To read the average temperature
1. Turn the control knob so that the ring on the axis
with the week number is selected.
2. Press the OK button.
3. Follow the grey line on the graph to read the average in-
door temperature for the selected week.
4. You can now take readings for different weeks
by turning the control knob to the right or left and
reading the average temperature.
5. Press the OK or Back button to exit read mode.
week
indoor temp.°C
indoor temp. log3.5
CAUTION
For these functions to work the network cable must
be connected.
Section 9 | Control
