Nibe F1226 series User Manual

F1226-12F1226-8F1226-6Model
Heating medium circuit
0.05 (0.5 bar) / 0.45 (4.5 bar)MPaMin/Max system pressure heating medium
0.180.120.09l/sMin flow
0.250.160.13l/sNominal flow
574753kPaMax external avail. press at nom flow
see diagram°CMin/max HM-temp
Noise
444443dB(A)Sound power level (L
WA
) according to EN 12102 at 0/35
292928dB(A)Sound pressure level (L
PA
) calculated values according to EN ISO 11203 at
0/35 and 1 m range
Pipe connections
282828Brine ext diam. CU pipe
282222Heating medium ext diam. CU pipes
22Hot water connection external diam
22Cold water connection external diam
1)
Max. permitted impedance in the mains connection point in accordance with EN 61000-3-11. Start currents can cause short voltage
dips that may affect other equipment in unfavourable conditions. If the impedance in the mains connection point is higher than that
stated, it is possible that interference will occur. If the impedance in the mains connection point is higher than that stated, check with the
power supplier before purchasing the equipment.
Miscellaneous
F1226-12F1226-8F1226-6Miscellaneous
Water heater
180Volume water heater
1.0 (10 bar)Max pressure in water heater
Compressor oil
POEOil type
1.891.331.33lVolume
Dimensions and weight
1,800 x 600 x 620mmHeight (including feet) x width x depth
1,950mmRequired ceiling height
1)
235225215kgWeight complete heat pump, stainless steel
255245235kgWeight complete heat pump, copper
130120112kgWeight only cooling module
065 230065 229065 228Part no., 3x400V, stainless steel
065 227065 226065 220Part no., 3x400V, copper
1)
With feet removed, the height is approx. 1930 mm.
NIBE F1226Chapter 12 | Technical data50

Nibe F1226 series Specifications

General

Type	Ground Source Heat Pump
Refrigerant	R407C
Dimensions (HxWxD)	1800 x 600 x 620 mm
Max Flow Temperature	58°C
Integrated Hot Water Tank	Yes
Control System	Nibe SMO 20
Power Supply	400V 50Hz
