MENU 5.3.16 - HUMIDITY SENSOR
climate system 1 HTS
Setting range: 1–4
Default value: 1
limit RH in the room, syst.
Setting range: on/off
Factory setting: off
prevent condensation, syst.
Setting range: on/off
Factory setting: off
Up to four humidity sensors (HTS 40) can be installed.
Here you select whether your system(s) is/are to limit
the relative humidity level (RH) during heating or cooling
operation.
You can also choose to limit min. cooling supply and
calculated cooling supply to prevent condensation on
pipes and components in the cooling system.
See the Installer Manual for HTS 40 for function descrip-
tion.
MENU 5.3.18 - POOL
Here you select which pump to use in the system.
MENU 5.3.19 - ACTIVE COOLING 4 PIPE
Here you select which pump to use in the system.
MENU 5.3.21 - FLOW SENSOR / ENERGY
METER
flow sensor / energy meter X22, X23
set mode
Setting range: energy per pulse / pulses per kWh /
EMK150 / EMK300/310 / EMK500
Default value: energy per pulse
energy per pulse
Setting range: 0 10000 Wh
Factory setting: 1000 Wh
pulses per kWh
Setting range: 1 10000
Factory setting: 500
Up to two flow sensors (EMK) / energy meters can be
connected on the input board AA3, terminal block X22
and X23. Select these in menu 5.2.4 - accessories.
Energy meter (Electricity meter)
energy per pulse: Here you set the amount of energy
to which each pulse will correspond.
pulses per kWh: Here you set the number of pulses per
kWh that are sent to VVM 320.
Flow sensor (Energy meter kit EMK)
A flow sensor (EMK) is used to measure the amount of
energy produced and supplied by the heating installation
for hot water and heating in the building.
The function of the flow sensor is to measure flow and
temperature differences in the charge circuit. The value
is presented in the display on a compatible product.
Starting from software version 8801R2 , you can select
the flow sensor (EMK) you have connected in the sys-
tem.
Caution
The software in VVM 320 must be software
version 8801R2 or later. Visit nibeuplink.com
and click on the "Software" tab to download
the latest software to your installation.
MENU 5.4 - SOFT IN/OUTPUTS
Here you can select which input/output on the input
board (AA3) the external contact function (page 34) must
be connected to.
Selectable inputs on terminal block AUX 1-5 (AA3-X6:9-
18) and output AA3-X7 on the input board.
59Chapter 8 | Control - MenusNIBE VVM 320
