19 - BOARD NOMENCLA
TURE
Function select
Display select
Spare fuses
Incoming 30
Amp fuse
Reset Hard Shut
down button
LCD screen
OK or Enter
Selection down
Selection up
Open the gate
Stop gate
movement
Close the gate
Figure - GENERAL BOARD OVERVIEW
THE PROGRAMMING BUTTONS INDICA
TED IN THE ABOVE REFERENCE SHOULD BE USED ONL
Y AFTER UNDERST
ANDING THE
MANUAL AND ITS RELA
TION TO THE PROGRAMMING SEQUENCES SHOWN ON THE FOLLOWING P
AGES. CARE SHOULD BE T
AKEN
WHENEVER CHANGES ARE IMPLEMENTED TO ENSURE PROPER FUNCTIONALITY AND SAFETY
.
Force select
Speed select
Delay select
37
39
