5
P/N Name Note
CBOX1050 Control Box
#816-1
816 Actuator
with 8’ harness
#816-2
816 Actuator
with 42’
harness
Add for
Dual Gate
Applications
#1116 Pivot Arm
Included in
816-1/816-2
#10025215
Gate Attach
Bracket
Included in
816-1/816-2
#1125 Bolt Kit
Included in
816-1/816-2
ABF/A
Directional
antenna
433 kHz kit
Included in
CBOX
OXI/A
Nice Radio
Receiver
EPMB/A
BlueBus
Photo Eye
1.4 Product Specifi cations
Model 1551
Duty Cycle
Varies based on Charger
Type
Drive Electromechanical
Gate Length Max. 16 ft (5 m ) leaf
Gate Weight Max 600 lb (272 kg)
Open/Close Time
(to 90°)
14 - 16s (adjustable)
Temperature
Rating
-4º to 122º F
(-20º to 50º C)
Operating
Voltage
12VDC
Input Voltage 10 - 32VDC
Idle Current
110 mA (awake)
10 mA (in Standby)
Accessory Power
12VDC and 24VDC
300 mA each
Actuator
Dimensions
816: 42 retracted -
66 extended
(107cm - 167.6cm)
User Controls 1050 board
Relays 2 programmable relays
Enclosure
CBOX: Type 3R,
18w x 18h x 8d inch
( 46w x 46h x 20.3d cm)
Listed to UL325 Usage Class I, II, III, IV
1.5
The installation of this product is not a “do-
it-yourself” project. A qualifi ed gate operator
installation company should be contacted
to install the gate operator to ensure a safe
and reliable installation. Since many aspects
of gate system installation are under the
control of the installer, it is the responsibility
of the property owner to ensure the installer
is qualifi ed to carry out the installation in a
safe and professional manner.
1.6
Consult local government agencies for
up-to-date rules and regulations as certain
municipalities have established licensing,
codes or regulations that regulate automated
gate system design and installation.
